VL802

LTE Vehicle Terminal
GPS Tracker for Vehicles​

The VL802 is an advanced 4G GPS tracker designed to manage industrial and commercial fleets ranging from passenger cars and trucks to buses. This device’s two-way communication can help fleet managers improve driver management strategies. LTE communication with GSM (2G) fallback ensures a solid connection in almost all cases, and the suite of event-triggered alerts helps fleet managers monitor the status of their fleet in real time. With RS485 interface and various other I/Os for peripherals, this powerful device can be customized to streamline your operations and boost efficiency.

VL802
LTE Vehicle Terminal
GPS Tracker for Vehicles​

The VL802 is an advanced 4G GPS tracker designed to manage industrial and commercial fleets ranging from passenger cars and trucks to buses. This device’s two-way communication can help fleet managers improve driver management strategies. LTE communication with GSM (2G) fallback ensures a solid connection in almost all cases, and the suite of event-triggered alerts helps fleet managers monitor the status of their fleet in real time. With RS485 interface and various other I/Os for peripherals, this powerful device can be customized to streamline your operations and boost efficiency.

FEATURES
SPECIFICATIONS
DOWNLOADS
LTE Cat M1_NB2 & GSM、LTE & GSM Network
LTE & GSM Network
Communication via 4G LTE networks with 2G GSM fallback.
Two-way Communication
Two-way Communication
Hands-free communication with your employee instead of using the phone!
Remote Listen-in
Remote Listen-in
Inconspicuous mic allows for remote audio monitoring of the environment around the device.
Panic Button
Panic Button
Contact dispatch or emergency support with a discreet, in-cabin SOS button.
Ignition Detection
Ignition Detection
Constantly detect the ACC/ignition status of the vehicle.
Remote Cut-Off (Fuel_Power)
Remote Cut-Off (Fuel/Power)
Immobilize a vehicle by cutting off its power source/fuel supply via an installed relay.
Bluetooth Configuration、Bluetooth Accessory Compatibility (Optional)
Bluetooth Configuration
Fast and simple device configuration via app for iOS and Android.
Multiple Alerts
Multiple Alerts
Instant alerts for atypical events such as impounding, geo-fence entry/exit, abnormal vibration, speeding, etc.
GNSS
Positioning system GPS+BDS+LBS
Positioning accuracy <2.5m CEP
Tracking sensitivity -162dBm
Acquisition sensitivity -160dBm
TTFF (open sky) Avg. hot start ≤1sec
Avg. cold start ≤32sec
Cellular
Communication network LTE Cat 1/GSM
Frequency VL802-E:
LTE-FDD: B1/B3/B7/B8/B20/B28
LTE-TDD: B34/B38/B39/B40/B41
GSM: 850/900/1800/1900MHzVL802-L:
LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B28
GSM: 850/900/1800/1900MHz
Power
Battery 1,000mAh/3.7V industrial-grade Li-Polymer battery
Input voltage 9-36VDC
Interface
LED indication GNSS (Green), Cellular (Blue), Power (Red)
SIM Micro-SIM
Data storage 16+16MB
Digital inputs ACC, SOS
Digital outputs Relay
Configurable I/O 2 special I/Os can be configured as extra digital inputs or outputs
Analog detect Support 0-5V
Physical specification
Dimensions 105 x 56 x 22mm
Weight 120g
Operating environment
Operating temperature –20℃ to +70℃
IP rating IP65
Feature
Sensors Accelerometer
Scenarios SOS alert, Speeding alert, Abnormal vibration alert, Fatigue driving alert

* We reserve the right to the final interpretation of this page. All information is for reference only and is subject to change without further notice.

APPLICATIONS
Fleet Management
Auto Insurance
Public Transport
APPLICATIONS
Fleet Management
Auto Insurance
Public Transport
