X3

Vehicle Tracker

Multifunctional Vehicle Tracker
X3 Multifunctional Vehicle Tracker Concox

X3 Multifunctional Vehicle Tracker

X3, a multifunctional GPS tracker, is optimized for vehicle tracking. It provides accurate real-time location, two-ways communication and driving behavior event, supports multiple sensors such as G-sensor and door-sensor; supports multiple external equipment for various applications. X3 is an extensible GPS tracking device for fleet management and security monitoring deployment.

Share to:

Feature

RS232 & TTL Interface
Support the accessories supporting RS232 and TLL interface.
External Mic
Extended microphone cable makes it easier to put microphone inside cab.
Remote Cut-Off (Fuel/Power)
Immobilize a vehicle by cutting off its power source/fuel supply via an installed relay.
Over-speed Buzzer
Sound buzz to remind driver to lower speed.
Driving Behavior Analysis (Basic)
Receive alerts when any of 4 kinds of dangerous driving behavior is detected.
Door Status Detection
Useful insight into the status of a fleet vehicle; be alerted if a door is unexpectedly opened.
Panic Button
Contact dispatch or emergency support with a discreet, in-cabin SOS button.
IPX5 Water Resistance
Rugged design ensures continued optimal performance, even in the toughest conditions.



Spec


GNSS


Positioning system GPS+BDS+LBS
Frequency L1
Positioning accuracy <2.5m CEP
Track sensitivity -165dBm
Acquisition sensitivity -148dBm
TTFF (open sky) Avg. hot start ≤1sec
Avg. cold start ≤35sec


Cellular


Communication network GSM
Frequency Quad-band 850/900/1800/1900 MHz



Power



Battery 450mAh/3.7V industrial-grade Li-Polymer battery
Input voltage 9-36VDC


Interface


LED indication GNSS (Blue), Cellular (Green), Power (Red)
SIM Standard-SIM
Data storage 32+32Mb
Digital inputs ACC, input, SOS
Digital outputs Relay, output1, output2



Physical specification



Dimensions 80.9 x 55.8 x 23.4mm
Weight 95g


Operating environment


Operating temperature –20℃ to +70℃


Feature


Voice monitoring range ≤5 meters
Sensors Accelerometer
Scenarios Vehicle movement alert, Over-speed alert, Geo-fence, Voice Monitoring, Vehicle battery detection, Power supply disconnection
Driving behavior analysis Harsh acceleration, Harsh braking, Harsh cornering, Collision

* We reserve the right of final interpretation of this page. All information is for reference only and is subject to change without further notice.
