EG02

E-scooter GPS Tracker
The JIMI EG02 Intelligent motorbike tracker comes with a plug & play design and supports GPS & LBS real-time tracking. Pls feel free to contact us

Say goodbye to traditional electric scooter keys and meet the effective anti-theft EG02. As small as a cigarette lighter, the EG02 GPS tracker comes with a plug & play design and supports GPS & LBS real-time tracking. Through the app, you can easily lock and unlock your E-bike remotely. An audio alarm will be triggered if the unauthorized movement of the E-bike is detected. The 9-90V wide working voltage enables EG02 to be applied to different E-bike models in the market.

EG02
E-scooter GPS Tracker
The JIMI EG02 Intelligent motorbike tracker comes with a plug & play design and supports GPS & LBS real-time tracking. Pls feel free to contact us

Say goodbye to traditional electric scooter keys and meet the effective anti-theft EG02. As small as a cigarette lighter, the EG02 GPS tracker comes with a plug & play design and supports GPS & LBS real-time tracking. Through the app, you can easily lock and unlock your E-bike remotely. An audio alarm will be triggered if the unauthorized movement of the E-bike is detected. The 9-90V wide working voltage enables EG02 to be applied to different E-bike models in the market.

FEATURES
SPECIFICATIONS
DOWNLOADS
Vehicle Battery Protection
Vehicle Battery Protection
Optimized battery protection prevents vehicle batteries from draining out or damage.
Automatic Wheel Lock
Automatic Wheel Lock
In arming mode, the device locks the e-scooter automatically if abnormal moving is detected.
9-90V Operating Voltage、9-36V Operating Voltage
9-90V Operating Voltage
Wide operating voltage range is suitable for a huge variety of vehicles, including industrial equipment, scooters, golf carts, and more.
Speeding Buzzer、External Buzzer Support
External Buzzer Support
External siren for alarms e-scooter searching.
Intelligent Theft Deterrence
Intelligent Theft Deterrence
Switch off electricity automatically to enter the arming status.
Plug and Play
Plug and Play
Designed for e-scooter connection ports, no need to cut wires.
Keyless Start
Keyless Start
Start the e-scooter through the mobile APP or SMS.
Multiple Alerts
Multiple Alerts
Instant alerts for atypical events such as abnormal vibration, speeding, power-off, geo-fenc entry/exit, etc.
GNSS
Positioning system GPS + LBS
Frequency L1
No. of GPS channels 66
Positioning accuracy <2.5m CEP
Tracking sensitivity –165dBm
Acquisition sensitivity –148dBm
TTFF (open sky) Avg. hot start ≤2sec
Avg. cold start ≤32sec
Cellular
Communication network GSM
Frequency 850/900/1800/1900 MHz
GPRS Class 12, TCP/IP
Phase error RMSPE<5, PPE<20
Max output GSM850/GSM900: 33±2dBm
GSM1800/GSM1900: 30±3dBm
Max frequency error ±0.1ppm
Receive sensitivity ±Class II RBER2% (-102dBm)
Power
Battery 270mAh/3.7V Lithium-polymer battery
Input voltage 9-90VDC/8mA (36VDC)
Standby current ≤5mA (by battery)
Interface
Data storage 64Mb
SIM Micro-SIM
Antenna Bullit-in GPS antenna, GSM quad-band antenna
Physical specification
Dimensions 77.0 x 29.0 x 13.0mm
Weight 43g
Operating environment
Operating temperature –20℃ to +70℃
IP rating IPX5

* We reserve the right of final interpretation of this page. All information is for reference only and is subject to change without further notice.
