The JC120 front-facing dash cam features a 110-degree field of view (horizontal) that captures and saves important details in 1080P HD video footage. This is a good choice for a wide range of applications–ride-hailing fleets, insurance telematics, car dealerships, private cars, and more.
The JC120 front-facing dash cam features a 110-degree field of view (horizontal) that captures and saves important details in 1080P HD video footage. This is a good choice for a wide range of applications–ride-hailing fleets, insurance telematics, car dealerships, private cars, and more.
The JC120 dash camera is rather small (88x56x48mm), making it perfect or capturing video without blocking your view of the road ahead. The power cable can be tucked in the trims for a tidy and discreet installation.
| Network | |
| Standard | 4G LTE Cat.1 bis |
| Frequency Bands | FDD LTE: Bands 1, 3, 7, 8, 20, and 28
GSM: Bands 3 and 8 |
| WiFi | 2.4GHz (802.11 b/g/n) |
| Configuration | |
| Positioning Method | GPS/BDS/AGPS/LBS (Built-in antenna) |
| CPU | UIS8910DM |
| Memory | 8MB+16MB |
| Operating System | RTOS |
| Sensor | 3-axis |
| Mic | ✓ |
| Speaker | ✓ |
| Camera | |
| Front Camera | History video resolution: 1080P, 25PS, full-color
Live streaming resolution: 480P, 15FPS, full-color Angle of view: 130° (D), 110° (H), 60° (V) |
| Video Coding | H.264+AAC |
| Image Coding | JPEG, 1080P |
| Others | |
| Memory Card | TF card (max. 128GB) |
| SIM Card | Nano |
| Extension Interface | UART*1 (Extension I/O cable is required) |
| Indicators | Red (power), Green (GNSS), Blue (cellular) |
| Keys | Key 1: Mute or unmute video (short press)/WiFi on or off (long press);
Key 2: Video off for now or recover video; Key 3: Take image and upload; Key 4: Mute or unmute speaker (short press)/SOS (long press) |
| Battery | DC 9–30V (Suitable for 12V and 24V vehicles) |
| Environment Requirement | Operating temperature: –20℃ to +70℃
Storage temperature: –30℃ to +85℃ |
* We reserve the right of final interpretation for this product. All information is for reference only and is subject to change without further notice.
